Hey guys! Let's dive into a common physics problem: figuring out the effective voltage of a sinusoidal generator. We're going to break down a question where the voltage equation is given, and we need to find that crucial effective voltage. This is super useful stuff for anyone studying electricity and magnetism, especially when you're dealing with alternating current (AC) circuits. So, grab your calculators, and let’s get started!

Understanding the Problem: The Sinusoidal Voltage Equation

So, the core of this problem lies in understanding the sinusoidal voltage equation. We are given:

V = 60 sin 100πt

Where:

  • V is the instantaneous voltage in volts.
  • t is the time in seconds.

This equation tells us how the voltage changes over time in a sinusoidal pattern. The 60 in front of the sin function represents the peak voltage (Vpeak). This is the maximum voltage the generator produces during each cycle. But, what we need is the effective voltage, also known as the root mean square (RMS) voltage. The effective voltage is what we'd measure with a standard voltmeter, and it's the voltage that tells us the equivalent DC voltage that would deliver the same power to a resistive load. Think of it as the "average" voltage in a way, but it's a special kind of average that takes into account the changing nature of AC.

The 100π part is related to the angular frequency (ω) of the AC signal, which tells us how fast the voltage oscillates. We'll see later why this is important, but for now, the most important piece of information is the peak voltage.

The Key Formula: From Peak to Effective Voltage

Now comes the crucial part: how do we get from peak voltage to effective voltage? There's a simple formula for this, and it's your best friend when dealing with AC circuits:

Veff = Vpeak / √2

Where:

  • Veff is the effective voltage (what we want to find).
  • Vpeak is the peak voltage (given in the equation).

This formula arises from the mathematical relationship between the sine wave and the RMS value. It essentially scales down the peak voltage to account for the fact that the voltage is not constantly at its peak value – it's oscillating! The square root of 2 (approximately 1.414) is the magic number that makes this conversion work. It’s a fundamental constant in AC circuit analysis, so make sure you remember it!

Solving the Problem: Step-by-Step

Alright, let's put this knowledge into action and solve the problem step-by-step.

  1. Identify the Peak Voltage: From the equation V = 60 sin 100πt, we can see that the peak voltage (Vpeak) is 60 volts. This is the maximum voltage the generator reaches during its cycle. Make sure you correctly identify this value from the equation – it’s the coefficient of the sine function.

  2. Apply the Formula: Now, we use the formula Veff = Vpeak / √2. Plug in the Vpeak value we just found:

    Veff = 60 / √2

  3. Calculate the Effective Voltage: Using a calculator, we can approximate the square root of 2 as 1.414. So, the equation becomes:

    Veff = 60 / 1.414 ≈ 42.42 volts

And there you have it! The effective voltage (Veff) is approximately 42.42 volts. This means that the sinusoidal voltage produced by this generator is equivalent to a steady DC voltage of 42.42 volts in terms of power delivery.

Why Effective Voltage Matters

You might be wondering, why do we even care about effective voltage? Why not just use the peak voltage? Well, the effective voltage is crucial because it gives us a meaningful measure of the voltage's ability to do work. As we mentioned earlier, it’s directly related to the power delivered to a load. Electrical appliances and systems are designed to operate at specific effective voltage levels. For example, in many countries, the standard household voltage is 120V or 240V, which refers to the effective voltage of the AC power supply. Using the peak voltage instead would lead to incorrect calculations and potentially damage equipment.

Consider a light bulb. The brightness of the light bulb depends on the power it dissipates, which is related to the square of the voltage. The effective voltage allows us to accurately calculate this power and ensure the light bulb operates correctly. Similarly, in electrical circuits, the current flowing through a resistor and the power dissipated are determined by the effective voltage. So, understanding and using effective voltage is fundamental to electrical engineering and circuit analysis.

Common Mistakes to Avoid

When working with effective voltage, it’s easy to make a few common mistakes. Let’s go over them so you can avoid them in the future:

  • Confusing Peak and Effective Voltage: This is the most common mistake. Remember, Vpeak is the maximum voltage, while Veff is the equivalent DC voltage. Always use the correct formula Veff = Vpeak / √2 to convert between them.
  • Forgetting the Formula: It might seem obvious, but forgetting the formula is a surefire way to get the wrong answer. Make sure you memorize this formula or have it handy when solving problems.
  • Using the Wrong Equation: Sometimes, problems might give you the angular frequency (ω) or the frequency (f) instead of directly providing the peak voltage. While these values are related, you'll still need to find the peak voltage first before calculating the effective voltage. Don't jump to conclusions and use the wrong numbers in your calculations.
  • Rounding Errors: When calculating the square root of 2, it’s best to use as many decimal places as possible or use the calculator's value to avoid rounding errors. These small errors can add up and affect your final answer.

Practice Makes Perfect

The best way to master effective voltage calculations is to practice! Look for more problems involving sinusoidal voltages and try to solve them step-by-step. Pay attention to the given information and make sure you're using the correct formulas. You can also try varying the peak voltage in the equation and see how it affects the effective voltage. This will help you develop a better intuition for how these concepts work.

Conclusion

So, guys, we've successfully tackled the problem of finding the effective voltage of a sinusoidal generator. Remember, the key is to identify the peak voltage from the equation and then use the formula Veff = Vpeak / √2. Understanding effective voltage is crucial for analyzing AC circuits and ensuring electrical systems operate safely and efficiently. Keep practicing, and you'll become a pro at these calculations in no time! If you have any questions or want to explore more physics concepts, just let me know. Happy calculating!
